LC815 Loading Conveyor

Product Overview

The JPH Equipment LC815 Loading Conveyor makes loading spreaders and trucks easy work. A 30t tipper can be loaded with Manure, Chicken Litter, Fertilizer, Dirt or even Compost in as little as 10 to 15 minutes (depending on material).

The job of clearing your chicken sheds, for example, loading straight into trucks becomes faster and easier with the LC815 loading conveyor long 4.5 meter clearance.

LC815 is equipped with a 10 meter long conveyor, is powered with a water cooled Kohler diesel engine and has a hydraulic drive to the belt. The belt and lift is remote controlled for easy use and allows the driver to stop/ start the belt and lift/lower the conveyor from the cabin of the bobcat etc.

Product Specs

10 meter conveyor,
Powering option (Either)
- 6.6kw diesel generator and 3phase electrical motor
- Powered with a water cooled diesel engine
Hydraulic belt drive
Remote control of belt and lift (conveyor height) for easy use, allows driver to stop/ start the belt or lift/lower the conveyor from the cabin of the bobcat.

Unit Specifications

Conveyor

- Overall length 10m
- Max lift height 4.5m
- Hopper size 0.9m (L) x 1.8m (H) x 2.4m (W)
- Belt width 0.8 m
- Wheel size 195/14

Towing

- Unit weight 1500 Kg
- Towing Supplied with standard 50mm tow ball

NOTE: The standard unit is only intended for towing around the farm, is not fitted with lights or brakes for registered road use.

Power

- Electric 4 Kva Electric motor 7~8kw generator can be mounted on the conveyor.
- Diesel Water cooled diesel engine 22hp aprox.

Material loading

- Throughput will vary depending on material viscosity and loading method 8-15 min for normal truck
